LC CABLOPOWER - 1,5mm2 to 35mm2/PVC/unshielded

Products

LC CABLOPOWER 2 x 1,5 mmq

Product ref. 10555165 - Country ref. F115002T300

  • Packaging: Cut to length (m)
  • 구조: 2x1,5
  • 코어수: 2
  • 도체 단면적: 1.5 mm²
  • 외경: 7.2 mm
  • Copper content: 30 kg/km
  • 무게(근사치): 74 kg/km



LC CABLOPOWER 3 x 1,5 mmq

Product ref. 10555178 - Country ref. F115003T300

  • Packaging: Cut to length (m)
  • 구조: 3G1,5
  • 코어수: 3
  • 도체 단면적: 1.5 mm²
  • 외경: 7.6 mm
  • Copper content: 45 kg/km
  • 무게(근사치): 79 kg/km



LC CABLOPOWER 4 x 1,5 mmq

Product ref. 10555260 - Country ref. F115004T300

  • Packaging: Cut to length (m)
  • 구조: 4G1,5
  • 코어수: 4
  • 도체 단면적: 1.5 mm²
  • 외경: 8.5 mm
  • Copper content: 60 kg/km
  • 무게(근사치): 102 kg/km



LC CABLOPOWER 5 x 1,5 mmq

Product ref. 10555214 - Country ref. F115005T300

  • Packaging: Cut to length (m)
  • 구조: 5G1,5
  • 코어수: 5
  • 도체 단면적: 1.5 mm²
  • 외경: 9.2 mm
  • Copper content: 75 kg/km
  • 무게(근사치): 123 kg/km



LC CABLOPOWER 6 x 1,5 mmq

Product ref. F115006T300 - Country ref. F115006T300

  • Packaging: Drum (1000m)
  • 구조: 6G1,5
  • 코어수: 6
  • 도체 단면적: 1.5 mm²
  • 외경: 10 mm
  • Copper content: 90 kg/km
  • 무게(근사치): 143 kg/km



Description

Description

Standards

  • Product
    UL and CSA approval

LC Cablopower for continuos moving application, high flexible and oil resistant.



Applications:

  • Tracksystem for tool machine
  • wood machine
  • automatic lines for assebly
  • handling
  • packaging
  • other application with moderate stresses

Characteristics

Characteristics

구조적 특성

구조적 특성

도체 재료
베어 구리 와이어
절연
폴리올레핀
Insulation colour
Black numbered Yellow/Green
Taping
Non woven tape
피복
폴리염화비닐
Sheath colour
Grey RAL 7001

전기적 특성

전기적 특성

Rated Voltage Uo/U
1000 V
시험전압
4000 V

기계적 특성

기계적 특성

Bending cycles
5 Mio.
Speed
300 m/min
Maximum acceleration
20 m/s²

사용 특성

사용 특성

Field of application
Dynamic
Minimum dynamic operating bending radius
6.5 (xD)
操作温度范围
-5 ... 80 °C
Storage temperature, range
-40 ... 80 °C
난연
IEC/EN 60332-1-2; FT1; UL 1581 FT1
Oil resistance
EN 50363-4-1
