CAN BUS PVC CABLES - fixed installation
CAN BUS PVC CABLES - fixed installation
CAN-BUS cables with PVC jacket for fixed installation, shielded, flame retardant
Read moreCAN BUS PVC (1x2x0.22)C
Nexans ref. 13-DRX24P01R - Country ref. 13-DRX24P01R
- Packaging: Drum (1000m)
- Construction type: (1x2x0.22)C
- Nominal outer diameter: 5.7 mm
- Copper content: 17 kg/km
- Approximate weight: 55 kg/km
CAN BUS PVC (2x2x0.22)C
Nexans ref. 13-DRX24P02R - Country ref. 13-DRX24P02R
- Packaging: Drum (1000m)
- Construction type: (2x2x0.22)C
- Nominal outer diameter: 7.6 mm
- Copper content: 35 kg/km
- Approximate weight: 69 kg/km
Description
Description
Standards
-
ProductUL and CSA approval
Applications
Interconnecting fieldbus cable for static application
BUS cables to connect Controller Area Network components
Normative references
CAN standard and customers requirements
UL recognized / CSA approval
Characteristics
Characteristics
Construction characteristics
Construction characteristics
Conductor material
Bare copper
Insulation
Foam-skin
Insulation colour
DIN 47100
Taping
Soft tape
Shielding
≥85% tinned copper braid coverage
Outer sheath
PVC
Sheath colour
Violet RAL 4001
Electrical characteristics
Electrical characteristics
Rated Voltage Uo/U
300 V
Characteristic impedance
120 Ohm
Test voltage
1500 V
Transmission characteristics
Transmission characteristics
Attenuation at 1 MHz
1.3 dB/100m
Attenuation at 5 MHz
3.1 dB/100m
Attenuation at 10 MHz
4.3 dB/100m
Attenuation at 20 MHz
6.4 dB/100m
Usage characteristics
Usage characteristics
Field of application
Static
Operating temperature, range
-20 ... 80 °C
Storage temperature, range
-30 ... 80 °C
Flame retardant
IEC/EN 60332-1-2; FT1; UL 1581 FT1
