CABLOPOWER - 0,5 mm² to 16 mm² / PVC-jacket / unshielded
CABLOPOWER - 0,5 mm² to 16 mm² / PVC-jacket / unshielded
Control cables for dynamic application up to 1000V, PVC jacket, unshielded, oil resistant, flame retardant, UL and CSA approved
Read moreCABLOPOWER 2 x 0,5 mm²
Product ref. 10554014
- Packaging: Cut to length (m)
- Construction type: 2x0,50
- Conductor cross-section: 0.5 mm²
- Number of cores: 2
- Outer Diameter: 5 mm
- Approximate weight: 32 kg/km
- Copper content: 10 kg/km
- Rated Voltage Uo/U: 1000 V
CABLOPOWER 3 G 0,5 mm²
Product ref. 10554022
- Packaging: Cut to length (m)
- Construction type: 3G0,50
- Conductor cross-section: 0.5 mm²
- Number of cores: 3
- Outer Diameter: 5.3 mm
- Approximate weight: 34 kg/km
- Copper content: 15 kg/km
- Rated Voltage Uo/U: 1000 V
CABLOPOWER 4 G 0,5 mm²
Product ref. 10553968
- Packaging: Cut to length (m)
- Construction type: 4G0,50
- Conductor cross-section: 0.5 mm²
- Number of cores: 4
- Outer Diameter: 5.7 mm
- Approximate weight: 41 kg/km
- Copper content: 20 kg/km
- Rated Voltage Uo/U: 1000 V
CABLOPOWER 5 G 0,5 mm²
Product ref. 10553977
- Packaging: Cut to length (m)
- Construction type: 5G0,50
- Conductor cross-section: 0.5 mm²
- Number of cores: 5
- Outer Diameter: 6.1 mm
- Approximate weight: 49 kg/km
- Copper content: 25 kg/km
- Rated Voltage Uo/U: 1000 V
CABLOPOWER 7 G 0,5 mm²
Product ref. 10553985
- Packaging: Cut to length (m)
- Construction type: 7G0,50
- Conductor cross-section: 0.5 mm²
- Number of cores: 7
- Outer Diameter: 7.2 mm
- Approximate weight: 69 kg/km
- Copper content: 35 kg/km
- Rated Voltage Uo/U: 1000 V
LC CABLOFLEX 12 x 0,5 mmq
Product ref. 10555309 - Country ref. F105012T100
- Packaging: Cut to length (m)
- Construction type: 12G0,50
- Conductor cross-section: 0.5 mm²
- Number of cores: 12
- Outer Diameter: 8.9 mm
- Approximate weight: 104 kg/km
- Copper content: 60 kg/km
- Rated Voltage Uo/U: 600 V
LC CABLOFLEX 18 x 0,5 mmq
Product ref. 10555316 - Country ref. F105018T100
- Packaging: Cut to length (m)
- Construction type: 18G0,50
- Conductor cross-section: 0.5 mm²
- Number of cores: 18
- Outer Diameter: 10.2 mm
- Approximate weight: 148 kg/km
- Copper content: 90 kg/km
- Rated Voltage Uo/U: 600 V
CABLOPOWER 25 G 0,5 mm²
Product ref. 10555321
- Packaging: Cut to length (m)
- Construction type: 25G0,50
- Conductor cross-section: 0.5 mm²
- Number of cores: 25
- Outer Diameter: 12.5 mm
- Approximate weight: 213 kg/km
- Copper content: 125 kg/km
- Rated Voltage Uo/U: 1000 V
CABLOPOWER 2 x 0,75 mm²
Product ref. 10555334
- Packaging: Cut to length (m)
- Construction type: 2x0,75
- Conductor cross-section: 0.75 mm²
- Number of cores: 2
- Outer Diameter: 5.4 mm
- Approximate weight: 40 kg/km
- Copper content: 15 kg/km
- Rated Voltage Uo/U: 1000 V
LC CABLOFLEX 3 x 0,75 mmq
Product ref. 10555282 - Country ref. F107503T100
- Packaging: Cut to length (m)
- Construction type: 3G0,75
- Conductor cross-section: 0.75 mm²
- Number of cores: 3
- Outer Diameter: 5.7 mm
- Approximate weight: 43 kg/km
- Copper content: 23 kg/km
- Rated Voltage Uo/U: 600 V
CABLOPOWER 3G0,75 mm²
Product ref.
- Packaging: Cut to length (m)
- Construction type: 3G0,75
- Conductor cross-section: 0.75 mm²
- Number of cores: 3
- Outer Diameter: 5.7 mm
- Approximate weight: 43 kg/km
- Copper content: 23 kg/km
- Rated Voltage Uo/U: 1000 V
CABLOPOWER 5 G 0,75 mm²
Product ref. 10555291
- Packaging: Cut to length (m)
- Construction type: 5G0,75
- Conductor cross-section: 0.75 mm²
- Number of cores: 5
- Outer Diameter: 6.7 mm
- Approximate weight: 63 kg/km
- Copper content: 38 kg/km
- Rated Voltage Uo/U: 1000 V
CABLOPOWER 7 G 0,75 mm²
Product ref. 10555297
- Packaging: Cut to length (m)
- Construction type: 7G0,75
- Conductor cross-section: 0.75 mm²
- Number of cores: 7
- Outer Diameter: 7.9 mm
- Approximate weight: 93 kg/km
- Copper content: 53 kg/km
- Rated Voltage Uo/U: 1000 V
CABLOPOWER 9 G 0,75 mm²
Product ref. 10555300
- Packaging: Drum (1000m)
- Construction type: 8G0,75
- Conductor cross-section: 0.75 mm²
- Number of cores: 8
- Outer Diameter: 8.4 mm
- Approximate weight: 112 kg/km
- Copper content: 60 kg/km
- Rated Voltage Uo/U: 1000 V
CABLOPOWER 12 x 0,75 mm²
Product ref. 10555370
- Packaging: Cut to length (m)
- Construction type: 12G0,75
- Conductor cross-section: 0.75 mm²
- Number of cores: 12
- Outer Diameter: 9.7 mm
- Approximate weight: 137 kg/km
- Copper content: 90 kg/km
- Rated Voltage Uo/U: 1000 V
CABLOPOWER 16 x 0,75 mm²
Product ref. 10555373
- Packaging: Cut to length (m)
- Construction type: 16G0,75
- Conductor cross-section: 0.75 mm²
- Number of cores: 16
- Outer Diameter: 10.9 mm
- Approximate weight: 179 kg/km
- Copper content: 120 kg/km
- Rated Voltage Uo/U: 1000 V
CABLOPOWER 18 x 0,75 mm²
Product ref. 10561912
- Packaging: Cut to length (m)
- Construction type: 18G0,75
- Conductor cross-section: 0.75 mm²
- Number of cores: 18
- Outer Diameter: 11.3 mm
- Approximate weight: 202 kg/km
- Copper content: 135 kg/km
- Rated Voltage Uo/U: 1000 V
CABLOPOWER 25 x 0,75 mm²
Product ref. 10561901
- Packaging: Cut to length (m)
- Construction type: 25G0,75
- Conductor cross-section: 0.75 mm²
- Number of cores: 25
- Outer Diameter: 13.9 mm
- Approximate weight: 289 kg/km
- Copper content: 188 kg/km
- Rated Voltage Uo/U: 1000 V
CABLOPOWER 26 x 0,75 mm²
Product ref. 10555386
- Packaging: Cut to length (m)
- Construction type: 26G0,75
- Conductor cross-section: 0.75 mm²
- Number of cores: 26
- Outer Diameter: 13.9 mm
- Approximate weight: 286 kg/km
- Copper content: 195 kg/km
- Rated Voltage Uo/U: 1000 V
CABLOPOWER 2 x 1,0 mm²
Product ref. 10555338
- Packaging: Cut to length (m)
- Construction type: 2x1
- Conductor cross-section: 1 mm²
- Number of cores: 2
- Outer Diameter: 5.8 mm
- Approximate weight: 48 kg/km
- Copper content: 20 kg/km
- Rated Voltage Uo/U: 1000 V
CABLOPOWER 3 G 1,0 mm²
Product ref. 10555346
- Packaging: Cut to length (m)
- Construction type: 3G1
- Conductor cross-section: 1 mm²
- Number of cores: 3
- Outer Diameter: 6.1 mm
- Approximate weight: 52 kg/km
- Copper content: 30 kg/km
- Rated Voltage Uo/U: 1000 V
CABLOPOWER 4 xG1,0 mm²
Product ref. 10555355
- Packaging: Cut to length (m)
- Construction type: 4G1
- Conductor cross-section: 1 mm²
- Number of cores: 4
- Outer Diameter: 6.6 mm
- Approximate weight: 65 kg/km
- Copper content: 40 kg/km
- Rated Voltage Uo/U: 1000 V
CABLOPOWER 5 G 1,0 mm²
Product ref. 10555364
- Packaging: Cut to length (m)
- Construction type: 5G1
- Conductor cross-section: 1 mm²
- Number of cores: 5
- Outer Diameter: 7.2 mm
- Approximate weight: 78 kg/km
- Copper content: 50 kg/km
- Rated Voltage Uo/U: 1000 V
CABLOPOWER 7 G 1,0 mm²
Product ref. 10555184
- Packaging: Cut to length (m)
- Construction type: 7G1
- Conductor cross-section: 1 mm²
- Number of cores: 7
- Outer Diameter: 8.5 mm
- Approximate weight: 115 kg/km
- Copper content: 70 kg/km
- Rated Voltage Uo/U: 1000 V
CABLOPOWER 8 G 1,0 mm²
Product ref. 10555187
- Packaging: Cut to length (m)
- Construction type: 8G1
- Conductor cross-section: 1 mm²
- Number of cores: 8
- Outer Diameter: 9.2 mm
- Approximate weight: 139 kg/km
- Copper content: 80 kg/km
- Rated Voltage Uo/U: 1000 V
CABLOPOWER 12 G 1,0 mm²
Product ref. 10555196
- Packaging: Cut to length (m)
- Construction type: 12G1
- Conductor cross-section: 1 mm²
- Number of cores: 12
- Outer Diameter: 10.5 mm
- Approximate weight: 175 kg/km
- Copper content: 120 kg/km
- Rated Voltage Uo/U: 1000 V
CABLOPOWER 16 G 1,0 mm²
Product ref. 10555200
- Packaging: Cut to length (m)
- Construction type: 16G1
- Conductor cross-section: 1 mm²
- Number of cores: 16
- Outer Diameter: 11.8 mm
- Approximate weight: 224 kg/km
- Copper content: 160 kg/km
- Rated Voltage Uo/U: 1000 V
CABLOPOWER 18 G 1,0 mm²
Product ref. 10555208
- Packaging: Cut to length (m)
- Construction type: 18G1
- Conductor cross-section: 1 mm²
- Number of cores: 18
- Outer Diameter: 12.4 mm
- Approximate weight: 253 kg/km
- Copper content: 180 kg/km
- Rated Voltage Uo/U: 1000 V
CABLOPOWER 25 G 1,0 mm²
Product ref. 10555150
- Packaging: Cut to length (m)
- Construction type: 25G1
- Conductor cross-section: 1 mm²
- Number of cores: 25
- Outer Diameter: 15.1 mm
- Approximate weight: 369 kg/km
- Copper content: 250 kg/km
- Rated Voltage Uo/U: 1000 V
CABLOPOWER 2 x 1,5 mm²
Product ref. 10555164
- Packaging: Cut to length (m)
- Construction type: 2x1,5
- Conductor cross-section: 1.5 mm²
- Number of cores: 2
- Outer Diameter: 6.4 mm
- Approximate weight: 63 kg/km
- Copper content: 30 kg/km
- Rated Voltage Uo/U: 1000 V
CABLOPOWER 3 G 1,5 mm²
Product ref. 10555177
- Packaging: Cut to length (m)
- Construction type: 3G1,5
- Conductor cross-section: 1.5 mm²
- Number of cores: 3
- Outer Diameter: 6.8 mm
- Approximate weight: 69 kg/km
- Copper content: 45 kg/km
- Rated Voltage Uo/U: 1000 V
CABLOPOWER 4 G 1,5 mm²
Product ref. 10555259
- Packaging: Cut to length (m)
- Construction type: 4G1,5
- Conductor cross-section: 1.5 mm²
- Number of cores: 4
- Outer Diameter: 7.4 mm
- Approximate weight: 87 kg/km
- Copper content: 60 kg/km
- Rated Voltage Uo/U: 1000 V
CABLOPOWER 5 G 1,5 mm²
Product ref. 10555213
- Packaging: Cut to length (m)
- Construction type: 5G1,5
- Conductor cross-section: 1.5 mm²
- Number of cores: 5
- Outer Diameter: 8.2 mm
- Approximate weight: 109 kg/km
- Copper content: 75 kg/km
- Rated Voltage Uo/U: 1000 V
CABLOPOWER 6 G 1,5 mm²
Product ref. 10555218
- Packaging: Cut to length (m)
- Construction type: 6G1,5
- Conductor cross-section: 1.5 mm²
- Number of cores: 6
- Outer Diameter: 8.9 mm
- Approximate weight: 127 kg/km
- Copper content: 90 kg/km
- Rated Voltage Uo/U: 1000 V
CABLOPOWER 7 G 1,5 mm²
Product ref. 10555228
- Packaging: Cut to length (m)
- Construction type: 7G1,5
- Conductor cross-section: 1.5 mm²
- Number of cores: 7
- Outer Diameter: 9.5 mm
- Approximate weight: 155 kg/km
- Copper content: 105 kg/km
- Rated Voltage Uo/U: 1000 V
CABLOPOWER 12 G 1,5 mm²
Product ref. 10555239
- Packaging: Cut to length (m)
- Construction type: 12G1,5
- Conductor cross-section: 1.5 mm²
- Number of cores: 12
- Outer Diameter: 12 mm
- Approximate weight: 239 kg/km
- Copper content: 180 kg/km
- Rated Voltage Uo/U: 1000 V
CABLOPOWER 18 G 1,5 mm²
Product ref. 10555564
- Packaging: Drum (1000m)
- Construction type: -
- Conductor cross-section: 1.5 mm²
- Number of cores: 18
- Outer Diameter: 14.6 mm
- Approximate weight: 392 kg/km
- Copper content: 270 kg/km
- Rated Voltage Uo/U: -
CABLOPOWER 3 G 2,5 mm²
Product ref. 10555529
- Packaging: Cut to length (m)
- Construction type: 3G2,5
- Conductor cross-section: 2.5 mm²
- Number of cores: 3
- Outer Diameter: 8 mm
- Approximate weight: 103 kg/km
- Copper content: 75 kg/km
- Rated Voltage Uo/U: 1000 V
CABLOPOWER 4 G 2,5 mm²
Product ref. 10555545
- Packaging: Cut to length (m)
- Construction type: 4G2,5
- Conductor cross-section: 2.5 mm²
- Number of cores: 4
- Outer Diameter: 8.7 mm
- Approximate weight: 130 kg/km
- Copper content: 100 kg/km
- Rated Voltage Uo/U: 1000 V
CABLOPOWER 5 G 2,5 mm²
Product ref. 10555552
- Packaging: Cut to length (m)
- Construction type: 5G2,5
- Conductor cross-section: 2.5 mm²
- Number of cores: 5
- Outer Diameter: 9.6 mm
- Approximate weight: 158 kg/km
- Copper content: 125 kg/km
- Rated Voltage Uo/U: 1000 V
CABLOPOWER 7 G 2,5 mm²
Product ref. 10555623
- Packaging: Cut to length (m)
- Construction type: 7G2,5
- Conductor cross-section: 2.5 mm²
- Number of cores: 7
- Outer Diameter: 11.6 mm
- Approximate weight: 233 kg/km
- Copper content: 175 kg/km
- Rated Voltage Uo/U: 1000 V
CABLOPOWER 12 G 2,5 mm²
Product ref. 10555630
- Packaging: Cut to length (m)
- Construction type: 12G2,5
- Conductor cross-section: 2.5 mm²
- Number of cores: 12
- Outer Diameter: 14.2 mm
- Approximate weight: 360 kg/km
- Copper content: 300 kg/km
- Rated Voltage Uo/U: 1000 V
Description
Description
Standards
-
ProductUL and CSA approval
Cables designed for continuous moving application, high flexible, oil resistance.
Applications:
- Tracksystems for tool machines
- Wood machines
- Automatic lines for assembly
- Handling
- Packaging
- Other applications with moderate stresses
Characteristics
Characteristics
Construction characteristics
Construction characteristics
Conductor material
Bare copper
Insulation
Polyolefin
Insulation colour
Black numbered Yellow/Green
Taping
Non woven tape
Outer sheath
PVC
Sheath colour
Grey RAL 7001
Electrical characteristics
Electrical characteristics
Test voltage
4000 V
Mechanical characteristics
Mechanical characteristics
Bending cycles
5 Mio.
Speed
300 m/min
Maximum acceleration
20 m/s²
Usage characteristics
Usage characteristics
Field of application
Dynamic
Operating temperature, range
-5 ... 80 °C
Storage temperature, range
-40 ... 80 °C
Minimum dynamic operating bending radius
6.5 (xD)
Flame retardant
IEC/EN 60332-1-2; FT1; UL 1581 FT1
Oil resistance
EN 50363-4-1
