MOVETRONIC PUR - 0,14mm2 to 0,34mm2/PUR/unshielded
MOVETRONIC PUR - 0,14mm2 to 0,34mm2/PUR/unshielded
Data and signal transmission cables for extremely dynamic application, PUR jacket, unshielded, oil resistant, flame retardant, halogen free, UL and CSA approved
Read moreMOVETRONIC PUR 2 x 0,14 mmq
Nexans ref. 10554112 - Country ref. F101402E200
- Packaging: Cut to length (m)
- Construction type: 2x0,14
- Conductor cross-section: 0.14 mm²
- Number of cores: 2
- Outer Diameter: 3.5 mm
- Copper content: 2.8 kg/km
- Approximate weight: 14 kg/km
MOVETRONIC PUR 3 x 0,14 mmq
Nexans ref. F101403E200 - Country ref. F101403E200
- Packaging: Drum (1000m)
- Construction type: 3x0,14
- Conductor cross-section: 0.14 mm²
- Number of cores: 3
- Outer Diameter: 3.7 mm
- Copper content: 4.2 kg/km
- Approximate weight: 15 kg/km
MOVETRONIC PUR 4 x 0,14 mmq
Nexans ref. F101404E200 - Country ref. F101404E200
- Packaging: Drum (1000m)
- Construction type: 4x0,14
- Conductor cross-section: 0.14 mm²
- Number of cores: 4
- Outer Diameter: 3.9 mm
- Copper content: 5.6 kg/km
- Approximate weight: 17 kg/km
MOVETRONIC PUR 5 x 0,14 mmq
Nexans ref. F101405E200 - Country ref. F101405E200
- Packaging: Drum (1000m)
- Construction type: 5x0,14
- Conductor cross-section: 0.14 mm²
- Number of cores: 5
- Outer Diameter: 4.2 mm
- Copper content: 7 kg/km
- Approximate weight: 20 kg/km
MOVETRONIC PUR 6 x 0,14 mmq
Nexans ref. F101406E200 - Country ref. F101406E200
- Packaging: Drum (1000m)
- Construction type: 6x0,14
- Conductor cross-section: 0.14 mm²
- Number of cores: 6
- Outer Diameter: 4.4 mm
- Copper content: 8.4 kg/km
- Approximate weight: 24 kg/km
MOVETRONIC PUR 8 x 0,14 mmq
Nexans ref. F101408E200 - Country ref. F101408E200
- Packaging: Drum (1000m)
- Construction type: 8x0,14
- Conductor cross-section: 0.14 mm²
- Number of cores: 8
- Outer Diameter: 5 mm
- Copper content: 11.3 kg/km
- Approximate weight: 34 kg/km
MOVETRONIC PUR 10 x 0,14 mmq
Nexans ref. F101410E200 - Country ref. F101410E200
- Packaging: Drum (1000m)
- Construction type: 10x0,14
- Conductor cross-section: 0.14 mm²
- Number of cores: 10
- Outer Diameter: 5.3 mm
- Copper content: 14.1 kg/km
- Approximate weight: 33 kg/km
MOVETRONIC PUR 14 x 0,14 mmq
Nexans ref. F101414E200 - Country ref. F101414E200
- Packaging: Drum (1000m)
- Construction type: 14x0,14
- Conductor cross-section: 0.14 mm²
- Number of cores: 14
- Outer Diameter: 5.7 mm
- Copper content: 19.7 kg/km
- Approximate weight: 42 kg/km
MOVETRONIC PUR 16 x 0,14 mmq
Nexans ref. F101416E200 - Country ref. F101416E200
- Packaging: Drum (1000m)
- Construction type: 16x0,14
- Conductor cross-section: 0.14 mm²
- Number of cores: 16
- Outer Diameter: 6 mm
- Copper content: 22.5 kg/km
- Approximate weight: 47 kg/km
MOVETRONIC PUR 18 x 0,14 mmq
Nexans ref. F101418E200 - Country ref. F101418E200
- Packaging: Drum (1000m)
- Construction type: 18x0,14
- Conductor cross-section: 0.14 mm²
- Number of cores: 18
- Outer Diameter: 6.2 mm
- Copper content: 25.3 kg/km
- Approximate weight: 52 kg/km
MOVETRONIC PUR 25 x 0,14 mmq
Nexans ref. F101425E200 - Country ref. F101425E200
- Packaging: Drum (1000m)
- Construction type: 25x0,14
- Conductor cross-section: 0.14 mm²
- Number of cores: 25
- Outer Diameter: 7.3 mm
- Copper content: 35.2 kg/km
- Approximate weight: 73 kg/km
MOVETRONIC PUR 2 x 0,25 mmq
Nexans ref. F102502E200 - Country ref. F102502E200
- Packaging: Drum (1000m)
- Construction type: 2x0,25
- Conductor cross-section: 0.25 mm²
- Number of cores: 2
- Outer Diameter: 3.9 mm
- Copper content: 5 kg/km
- Approximate weight: 18 kg/km
MOVETRONIC PUR 3 x 0,25 mmq
Nexans ref. F102503E200 - Country ref. F102503E200
- Packaging: Drum (1000m)
- Construction type: 3x0,25
- Conductor cross-section: 0.25 mm²
- Number of cores: 3
- Outer Diameter: 4.1 mm
- Copper content: 7.5 kg/km
- Approximate weight: 20 kg/km
MOVETRONIC PUR 4 x 0,25 mmq
Nexans ref. F102504E200 - Country ref. F102504E200
- Packaging: Drum (1000m)
- Construction type: 4x0,25
- Conductor cross-section: 0.25 mm²
- Number of cores: 4
- Outer Diameter: 4.4 mm
- Copper content: 10 kg/km
- Approximate weight: 24 kg/km
MOVETRONIC PUR 5 x 0,25 mmq
Nexans ref. F102505E200 - Country ref. F102505E200
- Packaging: Drum (1000m)
- Construction type: 5x0,25
- Conductor cross-section: 0.25 mm²
- Number of cores: 5
- Outer Diameter: 4.7 mm
- Copper content: 12.5 kg/km
- Approximate weight: 28 kg/km
MOVETRONIC PUR 6 x 0,25 mmq
Nexans ref. F102506E200 - Country ref. F102506E200
- Packaging: Drum (1000m)
- Construction type: 6x0,25
- Conductor cross-section: 0.25 mm²
- Number of cores: 6
- Outer Diameter: 5 mm
- Copper content: 15 kg/km
- Approximate weight: 33 kg/km
MOVETRONIC PUR 8 x 0,25 mmq
Nexans ref. F102508E200 - Country ref. F102508E200
- Packaging: Drum (1000m)
- Construction type: 8x0,25
- Conductor cross-section: 0.25 mm²
- Number of cores: 8
- Outer Diameter: 5.8 mm
- Copper content: 20.1 kg/km
- Approximate weight: 48 kg/km
MOVETRONIC PUR 10 x 0,25 mmq
Nexans ref. F102510E200 - Country ref. F102510E200
- Packaging: Drum (1000m)
- Construction type: 10x0,25
- Conductor cross-section: 0.25 mm²
- Number of cores: 10
- Outer Diameter: 6.1 mm
- Copper content: 25.1 kg/km
- Approximate weight: 53 kg/km
MOVETRONIC PUR 14 x 0,25 mmq
Nexans ref. F102514E200 - Country ref. F102514E200
- Packaging: Drum (1000m)
- Construction type: 14x0,25
- Conductor cross-section: 0.25 mm²
- Number of cores: 14
- Outer Diameter: 6.7 mm
- Copper content: 35.1 kg/km
- Approximate weight: 63 kg/km
MOVETRONIC PUR 16 x 0,25 mmq
Nexans ref. F102516E200 - Country ref. F102516E200
- Packaging: Drum (1000m)
- Construction type: 16x0,25
- Conductor cross-section: 0.25 mm²
- Number of cores: 16
- Outer Diameter: 7 mm
- Copper content: 40.1 kg/km
- Approximate weight: 70 kg/km
MOVETRONIC PUR 18 x 0,25 mmq
Nexans ref. F102518E200 - Country ref. F102518E200
- Packaging: Drum (1000m)
- Construction type: 18x0,25
- Conductor cross-section: 0.25 mm²
- Number of cores: 18
- Outer Diameter: 7.3 mm
- Copper content: 45.1 kg/km
- Approximate weight: 79 kg/km
MOVETRONIC PUR 25 x 0,25 mmq
Nexans ref. F102525E200 - Country ref. F102525E200
- Packaging: Drum (1000m)
- Construction type: 25x0,25
- Conductor cross-section: 0.25 mm²
- Number of cores: 25
- Outer Diameter: 8.6 mm
- Copper content: 62.7 kg/km
- Approximate weight: 110 kg/km
MOVETRONIC PUR 2 x 0,34 mmq
Nexans ref. F103402E200 - Country ref. F103402E200
- Packaging: Drum (1000m)
- Construction type: 2x0,34
- Conductor cross-section: 0.34 mm²
- Number of cores: 2
- Outer Diameter: 4.1 mm
- Copper content: 6.6 kg/km
- Approximate weight: 21 kg/km
MOVETRONIC PUR 3 x 0,34 mmq
Nexans ref. F103403E200 - Country ref. F103403E200
- Packaging: Drum (1000m)
- Construction type: 3x0,34
- Conductor cross-section: 0.34 mm²
- Number of cores: 3
- Outer Diameter: 4.3 mm
- Copper content: 9.9 kg/km
- Approximate weight: 23 kg/km
MOVETRONIC PUR 4 x 0,34 mmq
Nexans ref. F103404E200 - Country ref. F103404E200
- Packaging: Drum (1000m)
- Construction type: 4x0,34
- Conductor cross-section: 0.34 mm²
- Number of cores: 4
- Outer Diameter: 4.6 mm
- Copper content: 13.2 kg/km
- Approximate weight: 28 kg/km
MOVETRONIC PUR 5 x 0,34 mmq
Nexans ref. F103405E200 - Country ref. F103405E200
- Packaging: Drum (1000m)
- Construction type: 5x0,34
- Conductor cross-section: 0.34 mm²
- Number of cores: 5
- Outer Diameter: 5 mm
- Copper content: 16.5 kg/km
- Approximate weight: 33 kg/km
MOVETRONIC PUR 6 x 0,34 mmq
Nexans ref. F103406E200 - Country ref. F103406E200
- Packaging: Drum (1000m)
- Construction type: 6x0,34
- Conductor cross-section: 0.34 mm²
- Number of cores: 6
- Outer Diameter: 5.3 mm
- Copper content: 19.8 kg/km
- Approximate weight: 40 kg/km
MOVETRONIC PUR 8 x 0,34 mmq
Nexans ref. F103408E200 - Country ref. F103408E200
- Packaging: Drum (1000m)
- Construction type: 8x0,34
- Conductor cross-section: 0.34 mm²
- Number of cores: 8
- Outer Diameter: 6.1 mm
- Copper content: 26.4 kg/km
- Approximate weight: 57 kg/km
MOVETRONIC PUR 10 x 0,34 mmq
Nexans ref. F103410E200 - Country ref. F103410E200
- Packaging: Drum (1000m)
- Construction type: 10x0,34
- Conductor cross-section: 0.34 mm²
- Number of cores: 10
- Outer Diameter: 6.6 mm
- Copper content: 33 kg/km
- Approximate weight: 59 kg/km
MOVETRONIC PUR 14 x 0,34 mmq
Nexans ref. F103414E200 - Country ref. F103414E200
- Packaging: Drum (1000m)
- Construction type: 14x0,34
- Conductor cross-section: 0.34 mm²
- Number of cores: 14
- Outer Diameter: 7.1 mm
- Copper content: 46.2 kg/km
- Approximate weight: 77 kg/km
MOVETRONIC PUR 16 x 0,34 mmq
Nexans ref. F103416E200 - Country ref. F103416E200
- Packaging: Drum (1000m)
- Construction type: 16x0,34
- Conductor cross-section: 0.34 mm²
- Number of cores: 16
- Outer Diameter: 7.4 mm
- Copper content: 52.8 kg/km
- Approximate weight: 86 kg/km
MOVETRONIC PUR 18 x 0,34 mmq
Nexans ref. F103418E200 - Country ref. F103418E200
- Packaging: Drum (1000m)
- Construction type: 18x0,34
- Conductor cross-section: 0.34 mm²
- Number of cores: 18
- Outer Diameter: 7.8 mm
- Copper content: 59.4 kg/km
- Approximate weight: 97 kg/km
MOVETRONIC PUR 25 x 0,34 mmq
Nexans ref. F103425E200 - Country ref. F103425E200
- Packaging: Drum (1000m)
- Construction type: 25x0,34
- Conductor cross-section: 0.34 mm²
- Number of cores: 25
- Outer Diameter: 9.6 mm
- Copper content: 82.5 kg/km
- Approximate weight: 142 kg/km
Description
Description
Standards
-
ProductUL and CSA approval
Cables designed for continuous moving application, high flexible, oil resistance, halogen free
Applications:
- Tracksystems for tool machines
- Wood machines
- Automatic lines for assembly
- Handling
- Packaging
- Other applications with moderate stresses
