Study 133653

Characteristics

Very flexible cable with an extremely good mechanical behaviour.
Withstands miscellaneous sterilisation processes.

CONSTRUCTION

1- CORE (A)

AWG 38 silver plated copper wire.
FEP insulation.
Diameter : 0.30 +/- 0.02 mm

AWG 48 silver plated copper helicoidal screen
Nominal diameter : 0.36 mm

FEP jacket
Diameter : 0.53 +/- 0.03 mm

2- CORE (B)

8 Cores A twisted.
Nominal diameter : 1.63 mm

3- CORE (C)

2 Cores (A) twisted.
Nominal diameter : 1.07 mm

1 Kevlar strength member +
4 cores (B) + 1 core (C) twisted.
Nominal diameter : 3.70 mm

4- PTFE Tape
Nominal diameter : 3.84 mm

5- SHIELD
AWG 40 tin plated copper braid.
85% coverage.
Max. diameter : 4.35 mm

Main Characteristics
Minimum bending radius : 5 x Overall diameter.
